Home > products > Gold Plated Copper Wire >
Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications

Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications

Place of Origin:

CHINA

Brand Name:

WINNER

Certification:

ISO9100

Model Number:

SW-AC15

Contact Us
Request A Quote
Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications
Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications
Product Details
Resistance:
0.02 Ω/m
Corrosion Resistance:
Excellent
Wire Diameter:
0.2mm
Material:
Copper Alloy
Application:
Electronics, Jewelry, Crafts
Plating:
Gold
Product Type:
Bonding Wire
Wire Diameter:
0.001 Inches
Coating Thickness:
0.001mm
Material:
Copper
Coating:
Gold
Length Meters:
500/1000
Corrosion Resistance:
High
Purity:
99.999%
Bonding Method:
Ultrasonic
Temperature Range:
-40°C To 200°C
Surface Finish:
Bright
Conductivity:
98%
Package Size:
100 Meters
Bond Strength:
High
Package:
Spool
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
999
Packaging Details
Roll, Neutrial Packing or with OEM LOGO
Delivery Time
5-8 WORKING DAYS
Payment Terms
L/C, Western Union, T/T
Supply Ability
100000 rolls per month
RELATED PRODUCTS
Good price Smooth Surface Finish Gold Plated Copper Wire Electronics Jewelry Crafts online Video

Smooth Surface Finish Gold Plated Copper Wire Electronics Jewelry Crafts

Get Best Price
Good price 99.99% High Purity Gold Plated Copper Wire High Elasticity Corrosion Resistant online Video

99.99% High Purity Gold Plated Copper Wire High Elasticity Corrosion Resistant

Get Best Price
Good price High Conductivity Gold Plated Copper Wire For Electrical Systems 0.2mm online Video

High Conductivity Gold Plated Copper Wire For Electrical Systems 0.2mm

Get Best Price
Good price Anti Corrosion Gold Plated Copper Wire Electronics Jewelry Crafts online Video

Anti Corrosion Gold Plated Copper Wire Electronics Jewelry Crafts

Get Best Price
Contact Us
86-15818576616
sales@winner-sc.com
Contact Now
Product Description

Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications

Experience unparalleled versatility with our premium gold plated copper wire, engineered to deliver exceptional performance across industrial and creative domains. Combining 99.9% oxygen-free copper core with 24K micron-thin gold plating, this wire achieves 98% IACS conductivity while offering superior corrosion resistance (passes ASTM B117 500hr salt spray test).

Key Advantages for Engineers & Designers:
✓ Dual-Function Excellence - Optimized for both electrical transmission (low 1.72 μΩ·cm resistivity) and aesthetic applications
✓ Military-Grade Durability - Withstands 100+ bending cycles (per IEC 61189-3) and extreme temperatures (-50℃ to 180℃)
✓ Cost-Efficient Solution - 70% more affordable than solid gold wire with identical surface nobility
✓ Eco-Compliant - RoHS/REACH certified plating process with 0.3μm min. thickness

Performance-Driven Applications:
* High-frequency PCB interconnects requiring <0.1Ω impedance fluctuation
* Luxury jewelry crafting with permanent tarnish resistance
* Aerospace sensor systems demanding stable signal integrity
* Architectural lighting installations needing weatherproof conductors

Technical Superiority:
Tensile strength: 210-240 MPa
Elongation rate: 15-25%
Solderability: <0.5s wetting time at 350°C
Surface roughness: Ra ≤ 0.08μm

Available in 18-40 AWG (0.40mm-0.08mm) with custom spooling options (100m-5000m reels). All products include ISO 9001-certified quality documentation and conductive performance warranty.



Gold plated Copper Alloy Wire

Type

Ø Diameter

±1% μm

Breaking Load

BL(gf)

Elongation

EL(%)

Length

Meters

SW-AC1

18(0.7mil)

>4

3-20

500/1000

20(0.8mil)

>5

3-20

500/1000

23(0.9mil)

>5

3-20

500/1000

25(1.0mil)

>7

3-20

500/1000

Note: The above Diameter, BL, EL parameters can be customized according to customer requirements.







Application:

Application fields of gold-plated copper alloy wire: Conductive coil, Conductive slip ring, Electronic components



Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications 0

1.What kind of Enameled copper wire do Winner produce?

We focus on research and development of selfbonding magnet round copper wire, fine polyurethane magnet wire, selfbonding litz copper wire and selfbonding silk covered wire.



2.What's diameters available of the Enamelled copper wire ?

We specialize in fine and ultra fine enamelled copper wire,diameters available of our products is Φ0.018-0.50mm.



3.What's selfbonding enameled copper wire?

Selfbonding enamelled copper wire is a special type of enamelled wire with an additional adhesive enamel overcoat such as thermoplastic resin.This adhesive has a bonding feature, which is activated

by heat or solvents.

Once activated the adhesive bonds turn to turn windings into a compact self supporting coil.

The use of selfbonding wire may offer cost and manufacturing advantages in some winding applications

as bobbins, tape, varnishing, or impregnation may be eliminated.



4. Is possible to get any sample of selfbonding enamelled copper wire that you have in production?

Of course you can!

Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications 1



Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications 2



Luxurious and Resilient Gold Plated Copper Wire for Various Electrical and Decorative Applications 3
