Customizable Ultra Fine Gold Bonding Wire for Inner Lead Packaging in Integrated Circuits and Semiconductor Separators 0

1.What kind of Enameled copper wire do Winner produce?

We focus on research and development of selfbonding magnet round copper wire, fine polyurethane magnet wire, selfbonding litz copper wire and selfbonding silk covered wire.

2.What's diameters available of the Enamelled copper wire ?

We specialize in fine and ultra fine enamelled copper wire,diameters available of our products is Φ0.018-0.50mm.

3.What's selfbonding enameled copper wire?

Selfbonding enamelled copper wire is a special type of enamelled wire with an additional adhesive enamel overcoat such as thermoplastic resin.This adhesive has a bonding feature, which is activated

by heat or solvents.

Once activated the adhesive bonds turn to turn windings into a compact self supporting coil.

The use of selfbonding wire may offer cost and manufacturing advantages in some winding applications

as bobbins, tape, varnishing, or impregnation may be eliminated.

4. Is possible to get any sample of selfbonding enamelled copper wire that you have in production?

Of course you can!

Customizable Ultra Fine Gold Bonding Wire for Inner Lead Packaging in Integrated Circuits and Semiconductor Separators 1

Customizable Ultra Fine Gold Bonding Wire for Inner Lead Packaging in Integrated Circuits and Semiconductor Separators 2

Customizable Ultra Fine Gold Bonding Wire for Inner Lead Packaging in Integrated Circuits and Semiconductor Separators 3

Density:	19.34 g/cm3
Melting Point:	1063°C
Electrical Resistivity: (@20°C)	2.3 μΩ-cm
Electrical Conductivity: (@20°C)	75% (IACS)
Thermal Conductivity: (@20°C)	315 W/(m-K)
Fusing Current (10 mm x 25 μm)	0.52 A

Composition	Diameter		Tensile Strength (gms)	Elongation (%)
99.99% Au	0.7 mil	17.5 μm	3 - 10	2 - 6
	0.8 mil	20 μm	4 - 13	2 - 7
	0.9 mil	22.5 μm	5 - 16	2 - 8
	1.0 mil	25 μm	6 - 20	2 - 8
	1.3 mil	32.5 μm	10 - 45	2 - 10
	1.5 mil	37.5 μm	13 - 50	2 - 12
	1.7 mil	42.5 μm	15 - 60	2 - 12
	1.8 mil	45 μm	20 - 70	2 - 12
	2.0 mil	50 μm	25 - 85	2 - 15
	3.0 mil	75 μm	50 - 180	2 - 20
